Professional snow removal attachment for Municipal Trucks — Hardox wear steel, sub-zero rated to −40°C.
Models: T0840
HCN T0840 Guardrail washer: CE-certified guardrail washer for skid steers, wheel loaders, and excavators. Ideal for snow clearing, ice control, and winter…
Factory-direct pricing · Responds within 24 hours
Submit RFQ FormThe T0840 Guardrail washer from HCN Attachments Manufacture Co., Ltd is a heavy-duty skid steer / loader attachment engineered for global construction, municipal, and industrial OEM applications.
Typical specifications include Overall Width: 1970 · Overall Length: 672 · Overall Height: 1243. Mounting interfaces, hydraulic flow, and working width are configurable to your carrier model.
Request technical drawings and an export quote at hcn-atta.com · CE certified · ISO 9001:2015 · worldwide shipping.
| Specification | Value / Range |
|---|---|
| Overall Length (mm)(Mounting bracket not included) | 672 |
| Overall Width (mm) | 1970 |
| Overall Height (mm) | 1243 |
| Total Weight (kg) | 550 |
| Effective working width (mm) | 1000 |
| Number of spray nozzles (unit) | 2 sets × 5 |
| Brush bristle material(Optional) | PP multi-filament / debris strip |
| CleaningHeight(mm) | 0-1430 |
| Left/right side shift(mm) | 1390 |
| Main boom rotation(°) | 180 |
| Boom rotation(°) | 180 |
| Operating speed(km/h) | 5-20 |
| Mounting Carrier | Water tank truck |
Specifications may vary by model. Custom configurations available. Request exact spec sheet →
The HCN T0840 Guardrail washer is a snow & ice removal designed for installation on Municipal Trucks. It is manufactured at HCN Attachments' ISO 9001:2015-certified facility in Xuzhou, China, and supplied to contractors, rental fleets, OEM partners, and equipment distributors in more than 60 countries. When sourcing snow blower attachment, snow pusher, hydraulic snow blower, skid steer snow removal, wheel loader snow attachment, municipal snow equipment for export or fleet replacement, verify carrier weight class, hydraulic output, and mounting interface before order confirmation — HCN provides free compatibility checks on request.
HCN snow removal attachments — snow blowers, snow pushers, snow buckets, angle plows, and salt spreaders — are engineered for professional winter maintenance of roads, airports, parking lots, and municipal infrastructure. Designed for skid steer loaders and wheel loaders, our snow equipment delivers reliable performance in sub-zero operating conditions down to −40°C.
Available model designations: T0840. Specification values in the table below apply to the listed model range. If your carrier falls outside the published weight class, contact HCN engineering with the machine make, model, operating weight, and pin-to-pin dimensions — custom bracket fabrication is typically available within 15–30 working days.
HCN T0840 Guardrail washer units leave factory with CE conformity documentation, operator manual, and QC records. Standard in-stock configurations ship within 7–15 working days; custom specifications require 15–30 working days. Export terms are quoted FOB Qingdao or Shanghai unless otherwise agreed. Submit an RFQ with your machine model, working conditions, and destination country for pricing, lead time, and bracket fit confirmation.
The T0840 Guardrail washer is specified on the following project types. Each application below reflects real field use — not generic marketing claims.
On this type of project, the T0840 Guardrail washer reduces cycle time compared with manual methods by allowing the operator to work from the carrier cab. Municipal road and highway snow clearing after heavy snowfall events and winter storms
On this type of project, the T0840 Guardrail washer reduces cycle time compared with manual methods by allowing the operator to work from the carrier cab. Airport runway, taxiway, and apron snow removal to maintain aviation safety standards
On this type of project, the T0840 Guardrail washer reduces cycle time compared with manual methods by allowing the operator to work from the carrier cab. Commercial parking lot, logistics hub, and shopping center snow management and de-icing
On this type of project, the T0840 Guardrail washer reduces cycle time compared with manual methods by allowing the operator to work from the carrier cab. Stadium, university campus, and industrial park pathway and courtyard snow clearing
On this type of project, the T0840 Guardrail washer reduces cycle time compared with manual methods by allowing the operator to work from the carrier cab. Residential community and condominium complex parking area winter maintenance
Engineering and procurement teams typically evaluate the T0840 Guardrail washer against these design and manufacturing attributes:
Factory-published values for the T0840 Guardrail washer. Confirm final configuration against your carrier data sheet before purchase order release.
| Specification | Value / Range |
|---|---|
| Overall Length (mm)(Mounting bracket not included) | 672 |
| Overall Width (mm) | 1970 |
| Overall Height (mm) | 1243 |
| Total Weight (kg) | 550 |
| Effective working width (mm) | 1000 |
| Number of spray nozzles (unit) | 2 sets × 5 |
| Brush bristle material(Optional) | PP multi-filament / debris strip |
| CleaningHeight(mm) | 0-1430 |
| Left/right side shift(mm) | 1390 |
| Main boom rotation(°) | 180 |
| Boom rotation(°) | 180 |
| Operating speed(km/h) | 5-20 |
| Mounting Carrier | Water tank truck |
Specifications may vary by model. Custom configurations available. Request exact spec sheet →
Pushers maximize open-area productivity; blowers are required where snow cannot be pushed to an edge. Many municipal fleets deploy both on quick-attach carriers.
| Selection Criteria | Snow Pusher Box | Hydraulic Snow Blower |
|---|---|---|
| Operating method | Pushes accumulated snow to collection point | Collects and throws snow up to 20 m away |
| Best application | Large parking lots, logistics aprons, open roads | Airport taxiways, narrow lanes, confined spaces |
| Wet snow handling | Effective with containment box design | Auger auto-reverse prevents jamming on heavy wet snow |
| Procurement note | Lower capital cost; fastest on open areas | Required when pushing to edge is not permitted |
Manual clearing and walk-behind blowers suit small lots. Loader-mounted snow equipment is procured for route contracts, airport aprons, and logistics hubs with defined clearing SLAs.
| Method | Manual / Conventional Approach | HCN Attachment |
|---|---|---|
| Typical use | Shovel crews or walk-behind snow blowers — high labour cost, weather-dependent output, unsuitable for runways or large aprons | Hydraulic snow blower or pusher on skid steer/wheel loader — 600–1,200 t/hr output, single-operator coverage of large areas |
| When to specify | Specify a snow attachment when cleared area exceeds 5,000 m² per event, wet snow density exceeds 300 kg/m³, or contract SLA requires sub-30-minute runway/apron recovery | |
When reviewing Snow & Ice Removal for a purchase decision, these parameters determine whether the unit will perform on your site:
The HCN T0840 Guardrail washer is engineered for Municipal Trucks within HCN's rated weight and hydraulic output range. Send your exact carrier make, model, and pin-to-pin dimensions for a free compatibility confirmation before order placement. OEM-fit brackets are available for Caterpillar, Komatsu, Hitachi, Volvo, Doosan, Bobcat, and 30+ brands.
HCN manufactures a complete range of snow management equipment: hydraulic snow blowers (auger and impeller type), snow pusher boxes, snow buckets, straight angle plows, V-plows, and hydraulic salt and sand spreaders. All models are designed for skid steer loaders and wheel loaders, with optional excavator-mounted snow buckets available for rail yards and large sites.
A snow pusher (or containment pusher box) pushes accumulated snow across the surface to a collection point at the edge of the area. It is simple, fast, and ideal for large open parking lots and roads. A snow blower uses a hydraulically powered auger to collect snow and an impeller to throw it up to 20 metres away from the machine — essential for confined spaces like airport taxiways where pushing snow to an edge is not possible.
Yes. HCN snow blowers are rated for wet snow density up to 500 kg/m³ (typical fresh snow is 50–200 kg/m³; compacted wet snow reaches 400–500 kg/m³). The hydraulic auto-reverse feature prevents auger jamming, and a shear-bolt protection system prevents motor damage if a rock or foreign object is ingested.
HCN snow attachments are supplied with a universal skid steer attachment plate (ISO 24410 compliant) and are available with brand-specific adapter plates for Bobcat, CASE, Caterpillar, John Deere, Kubota, New Holland, and other brands. Custom attachment plates can be fabricated within 10 working days.
21,000 m² manufacturing campus in Xuzhou ETDZ — CNC laser cutting, robotic welding, in-house heat treatment, and PLM-controlled production. 400+ models, 500+ patents, export to 60+ countries.
Tour our factory →ISO 9001:2015, ISO 14001, ISO 45001, CE conformity on export lines, and National High-Tech Enterprise status. Full documentation available for tender and OEM audit submissions.
View certifications →Documented deployments: highway compaction in Southeast Asia, airport snow management in Northern Europe, and open-pit rock breaking in Australia — with measurable results.
Read case studies →Not sure which attachment fits your machine? Read our selection guide · Procurement FAQ
Include your machine model, working conditions, and destination country — our sales engineers respond within 24 business hours with pricing, lead time, and bracket fit confirmation.
