Hydraulic soil compaction attachment for Excavators — vibratory plate or drum compactor, CE & ISO 9001 certified.
Models: HN3940 · HN3960 · HN3972
HCN HN39 Vibratory Compactor: CE-certified compactor for excavators. Ideal for soil compaction and road base preparation. Key specs — Width 1320/1830/2130 mm…
Factory-direct pricing · Responds within 24 hours
Submit RFQ FormThe HN39 Vibratory Compactor from HCN Attachments Manufacture Co., Ltd is a heavy-duty skid steer / loader attachment engineered for global construction, municipal, and industrial OEM applications.
Typical specifications include Overall Width: 1320 / 1830 · Overall Length: 850 / 850 · Overall Height: 670 / 670. Mounting interfaces, hydraulic flow, and working width are configurable to your carrier model.
Request technical drawings and an export quote at hcn-atta.com · CE certified · ISO 9001:2015 · worldwide shipping.
| Specification | HN3940 | HN3960 | HN3972 |
|---|---|---|---|
| Overall Length (mm) | 850 | 850 | 850 |
| Overall Width (mm) | 1320 | 1830 | 2130 |
| Overall Height (mm) | 670 | 670 | 670 |
| Drum Diameter (mm) | Φ590 | Φ590 | Φ590 |
| Weight (Theoretical) (incl. Mount) (Kg) | 760 | 880 | 960 |
| Centrifugal Force (KN)@(L/Min) | 31 @ 60 | 37 @ 60 | 40 @ 70 |
| Hydraulic Flow (L/Min) | 60-70 | 60-70 | 60-70 |
| Maximum Allowable Pressure (MPa) | 20 | 20 | 20 |
| Compatible Carriers | Excavator | Excavator | Excavator |
Specifications may vary by model. Custom configurations available. Request exact spec sheet →
The HCN HN39 Vibratory Compactor is a compaction attachments designed for installation on Excavators. It is manufactured at HCN Attachments' ISO 9001:2015-certified facility in Xuzhou, China, and supplied to contractors, rental fleets, OEM partners, and equipment distributors in more than 60 countries. When sourcing vibratory compactor, soil compaction machine, construction compactor, hydraulic plate compactor, trench compactor, vibratory plate compactor, excavator compactor for export or fleet replacement, verify carrier weight class, hydraulic output, and mounting interface before order confirmation — HCN provides free compatibility checks on request.
HCN compaction attachments — vibratory plate compactors, trench compactors, drum rollers, and tamping rammers — deliver reliable high-frequency soil compaction for skid steers, wheel loaders, and excavators. These hydraulic soil compaction machines meet CE and ISO 9001:2015 standards and are used by contractors in 60+ countries for road construction, utility trench backfill, and foundation preparation.
Available model designations: HN3940, HN3960, HN3972. Specification values in the table below apply to the listed model range. If your carrier falls outside the published weight class, contact HCN engineering with the machine make, model, operating weight, and pin-to-pin dimensions — custom bracket fabrication is typically available within 15–30 working days.
HCN HN39 Vibratory Compactor units leave factory with CE conformity documentation, operator manual, and QC records. Standard in-stock configurations ship within 7–15 working days; custom specifications require 15–30 working days. Export terms are quoted FOB Qingdao or Shanghai unless otherwise agreed. Submit an RFQ with your machine model, working conditions, and destination country for pricing, lead time, and bracket fit confirmation.
The HN39 Vibratory Compactor is specified on the following project types. Each application below reflects real field use — not generic marketing claims.
On this type of project, the HN39 Vibratory Compactor reduces cycle time compared with manual methods by allowing the operator to work from the carrier cab. Utility trench backfill compaction after pipe, cable, or conduit installation in infrastructure projects
On this type of project, the HN39 Vibratory Compactor reduces cycle time compared with manual methods by allowing the operator to work from the carrier cab. Subbase and sub-grade compaction during road construction, resurfacing, and pavement rehabilitation
On this type of project, the HN39 Vibratory Compactor reduces cycle time compared with manual methods by allowing the operator to work from the carrier cab. Foundation and embankment compaction on civil engineering, residential, and commercial building sites
On this type of project, the HN39 Vibratory Compactor reduces cycle time compared with manual methods by allowing the operator to work from the carrier cab. Compacting granular fill — sand, gravel, and crushed stone — in confined or hard-to-reach areas
On this type of project, the HN39 Vibratory Compactor reduces cycle time compared with manual methods by allowing the operator to work from the carrier cab. Dam construction and earthwork compaction where large roller compactors cannot access
Engineering and procurement teams typically evaluate the HN39 Vibratory Compactor against these design and manufacturing attributes:
Factory-published values for the HN39 Vibratory Compactor. Confirm final configuration against your carrier data sheet before purchase order release.
| Specification | HN3940 | HN3960 | HN3972 |
|---|---|---|---|
| Overall Length (mm) | 850 | 850 | 850 |
| Overall Width (mm) | 1320 | 1830 | 2130 |
| Overall Height (mm) | 670 | 670 | 670 |
| Drum Diameter (mm) | Φ590 | Φ590 | Φ590 |
| Weight (Theoretical) (incl. Mount) (Kg) | 760 | 880 | 960 |
| Centrifugal Force (KN)@(L/Min) | 31 @ 60 | 37 @ 60 | 40 @ 70 |
| Hydraulic Flow (L/Min) | 60-70 | 60-70 | 60-70 |
| Maximum Allowable Pressure (MPa) | 20 | 20 | 20 |
| Compatible Carriers | Excavator | Excavator | Excavator |
Specifications may vary by model. Custom configurations available. Request exact spec sheet →
Plate and drum compactors serve different site geometries. Match the attachment type to your compaction surface — not just centrifugal force rating.
| Selection Criteria | Plate Compactor | Trench Drum Compactor |
|---|---|---|
| Contact surface | Flat plate — full-width soil contact | Cylindrical drum — compacts within trench width only |
| Best application | Open areas, subbase, embankments, parking lots | Utility trenches, narrow pipeline corridors |
| Soil disturbance | Compacts surrounding undisturbed soil at edges | Minimizes disturbance to trench sidewalls |
| Procurement note | Higher area coverage per pass | Specify drum width to match trench specification |
Walk-behind compactors remain standard for small trenches. Carrier-mounted compactors are specified when lift thickness, trench depth, or daily area targets exceed walk-behind output.
| Method | Manual / Conventional Approach | HCN Attachment |
|---|---|---|
| Typical use | Walk-behind vibratory plate — operator on ground, limited to shallow lifts and small footprints | Hydraulic plate or drum compactor on excavator/skid steer — compacts from cab, higher centrifugal force, reaches confined trenches via boom reach |
| When to specify | Specify a machine-mounted compactor when Proctor density targets require 80 kN+ force, trench width exceeds walk-behind coverage, or production rate exceeds 200 m²/shift | |
When reviewing Compaction Attachments for a purchase decision, these parameters determine whether the unit will perform on your site:
The HCN HN39 Vibratory Compactor is engineered for Excavators within HCN's rated weight and hydraulic output range. Send your exact carrier make, model, and pin-to-pin dimensions for a free compatibility confirmation before order placement. OEM-fit brackets are available for Caterpillar, Komatsu, Hitachi, Volvo, Doosan, Bobcat, and 30+ brands.
A vibratory plate compactor attachment (also called a hydraulic compactor, soil compaction machine, or construction compactor) mounts on a skid steer loader, wheel loader, or excavator boom. A hydraulically driven eccentric rotating mass inside the attachment generates high-frequency vertical vibrations that cause soil particles to settle tightly, increasing load-bearing capacity and reducing future settlement.
HCN compaction attachments are effective on granular soils (sand, gravel, crushed stone, road base), cohesive soils (silt and clay — using higher centrifugal force models), and mixed fill material. They are not recommended for organic topsoil or saturated, waterlogged soil without prior drainage.
A plate compactor has a flat base plate that contacts the soil across its full width — ideal for open areas and large surface compaction. A trench drum compactor has a cylindrical drum suited for narrow utility trenches because it compacts only within the trench width without disturbing surrounding undisturbed soil. HCN offers both in a range of sizes.
HCN compaction attachments are available for carriers from 1.5-tonne skid steer loaders to 30-tonne excavators. As a guide, the attachment weight should be approximately 8–12% of the carrier operating weight for stable operation during vibration cycles.
Yes. HCN trench drum compactors are available with drum widths from 300 mm, and narrow plate compactors start from 450 mm. These are specifically designed for utility pipeline trenches, basement floor compaction, and building foundation wall backfill in restricted-access sites.
21,000 m² manufacturing campus in Xuzhou ETDZ — CNC laser cutting, robotic welding, in-house heat treatment, and PLM-controlled production. 400+ models, 500+ patents, export to 60+ countries.
Tour our factory →ISO 9001:2015, ISO 14001, ISO 45001, CE conformity on export lines, and National High-Tech Enterprise status. Full documentation available for tender and OEM audit submissions.
View certifications →Documented deployments: highway compaction in Southeast Asia, airport snow management in Northern Europe, and open-pit rock breaking in Australia — with measurable results.
Read case studies →Not sure which attachment fits your machine? Read our selection guide · Procurement FAQ
Include your machine model, working conditions, and destination country — our sales engineers respond within 24 business hours with pricing, lead time, and bracket fit confirmation.
