Universal skid steer attachment for Wheel Loaders — ISO 24410 quick-attach, CE certified, factory direct.
Models: BM0520 · BM0530 · BM0550 · BM05A60
HCN BM05 Bucket: CE-certified bucket for wheel loaders. Ideal for construction, landscaping, and material handling. Key specs — Width 1942/2242/2940 mm…
Factory-direct pricing · Responds within 24 hours
Submit RFQ FormThe BM05 Bucket from HCN Attachments Manufacture Co., Ltd is a heavy-duty skid steer / loader attachment engineered for global construction, municipal, and industrial OEM applications.
Typical specifications include Overall Width: 1942 / 2242 · Overall Length: 1970 / 1140 · Overall Height: 860 / 1120. Mounting interfaces, hydraulic flow, and working width are configurable to your carrier model.
Request technical drawings and an export quote at hcn-atta.com · CE certified · ISO 9001:2015 · worldwide shipping.
| Specification | BM0520 | BM0530 | BM0550 | BM05A60 |
|---|---|---|---|---|
| Overall Width (mm) | 1942 | 2242 | 2940 | 3000 |
| Overall Length (mm) | 1970 | 1140 | 840 | 1490 |
| Overall Height (mm) | 860 | 1120 | 1330 | 1700 |
| Struck Capacity (m³) | 0.6 | 1.3 | 2.3 | 3.8 |
| StockpilingBucket Capacity(m³) | 0.8 | 1.7 | 2.7 | 5.0 |
| Weight (incl. Mount) (kg) | 380 | 700 | 1256 | 1900 |
| Compatible Carriers | 2T | 3T | 5T | 6T |
| Optional Accessories | Standard secondary cutting edge; optional bucket teeth | Standard secondary cutting edge; optional bucket teeth | Standard secondary cutting edge; optional bucket teeth | Standard secondary cutting edge; optional bucket teeth |
Specifications may vary by model. Custom configurations available. Request exact spec sheet →
The HCN BM05 Bucket is a general purpose attachments designed for installation on Wheel Loaders. It is manufactured at HCN Attachments' ISO 9001:2015-certified facility in Xuzhou, China, and supplied to contractors, rental fleets, OEM partners, and equipment distributors in more than 60 countries. When sourcing quick coupler attachment, pallet forks skid steer, hydraulic auger attachment, universal quick attach, skid steer attachments, wheel loader attachments for export or fleet replacement, verify carrier weight class, hydraulic output, and mounting interface before order confirmation — HCN provides free compatibility checks on request.
HCN general-purpose attachments — hydraulic quick couplers, pallet forks, auger drives, multi-purpose buckets, and work tool carriers — increase skid steer loader and wheel loader productivity by enabling rapid attachment changes and multi-task capability from a single machine. Universal ISO 24410 quick-attach systems let operators switch tools in under 60 seconds without leaving the cab.
Available model designations: BM0520, BM0530, BM0550, BM05A60. Specification values in the table below apply to the listed model range. If your carrier falls outside the published weight class, contact HCN engineering with the machine make, model, operating weight, and pin-to-pin dimensions — custom bracket fabrication is typically available within 15–30 working days.
HCN BM05 Bucket units leave factory with CE conformity documentation, operator manual, and QC records. Standard in-stock configurations ship within 7–15 working days; custom specifications require 15–30 working days. Export terms are quoted FOB Qingdao or Shanghai unless otherwise agreed. Submit an RFQ with your machine model, working conditions, and destination country for pricing, lead time, and bracket fit confirmation.
The BM05 Bucket is specified on the following project types. Each application below reflects real field use — not generic marketing claims.
On this type of project, the BM05 Bucket reduces cycle time compared with manual methods by allowing the operator to work from the carrier cab. Multi-task job sites requiring frequent tool changes — from bucket to forks to auger throughout the day
On this type of project, the BM05 Bucket reduces cycle time compared with manual methods by allowing the operator to work from the carrier cab. Warehousing, agriculture, and construction material handling using pallet forks and material buckets
On this type of project, the BM05 Bucket reduces cycle time compared with manual methods by allowing the operator to work from the carrier cab. Post-hole drilling for fencing, sign installation, tree planting, and foundation mini-piers
On this type of project, the BM05 Bucket reduces cycle time compared with manual methods by allowing the operator to work from the carrier cab. Rental fleet operations requiring one machine to handle multiple attachment types for various customers
On this type of project, the BM05 Bucket reduces cycle time compared with manual methods by allowing the operator to work from the carrier cab. Emergency response and utility maintenance where quick attachment changes maximize machine uptime
Engineering and procurement teams typically evaluate the BM05 Bucket against these design and manufacturing attributes:
Factory-published values for the BM05 Bucket. Confirm final configuration against your carrier data sheet before purchase order release.
| Specification | BM0520 | BM0530 | BM0550 | BM05A60 |
|---|---|---|---|---|
| Overall Width (mm) | 1942 | 2242 | 2940 | 3000 |
| Overall Length (mm) | 1970 | 1140 | 840 | 1490 |
| Overall Height (mm) | 860 | 1120 | 1330 | 1700 |
| Struck Capacity (m³) | 0.6 | 1.3 | 2.3 | 3.8 |
| StockpilingBucket Capacity(m³) | 0.8 | 1.7 | 2.7 | 5.0 |
| Weight (incl. Mount) (kg) | 380 | 700 | 1256 | 1900 |
| Compatible Carriers | 2T | 3T | 5T | 6T |
| Optional Accessories | Standard secondary cutting edge; optional bucket teeth | Standard secondary cutting edge; optional bucket teeth | Standard secondary cutting edge; optional bucket teeth | Standard secondary cutting edge; optional bucket teeth |
Specifications may vary by model. Custom configurations available. Request exact spec sheet →
Quick coupler type affects tool-change frequency, operator safety, and fleet utilization. Rental and multi-task fleets typically specify hydraulic couplers.
| Selection Criteria | Manual Quick Coupler | Hydraulic Quick Coupler |
|---|---|---|
| Tool change time | Operator exits cab to engage latch | Cab-mounted switch — under 60 seconds |
| Operator safety | Requires ground-level pin engagement | No ground exit during tool change |
| Best application | Single-tool, low-change-frequency sites | Rental fleets, multi-task contractors |
| Procurement note | Lower unit cost | Higher uptime; preferred for 4-season fleets |
Pin-on mounting suits single-tool machines. Quick-attach systems are specified when daily tool changes exceed two per shift or rental fleet utilisation depends on rapid changeover.
| Method | Manual / Conventional Approach | HCN Attachment |
|---|---|---|
| Typical use | Pin-on connection — 10–15 minute tool change, operator must exit cab, hammer and pin engagement | ISO 24410 quick coupler — under 60-second tool change from cab (hydraulic coupler), higher fleet utilisation |
| When to specify | Specify a quick coupler when the carrier performs 3+ attachment types per day or rental fleet downtime cost exceeds coupler capital cost within 12 months | |
When reviewing General Purpose Attachments for a purchase decision, these parameters determine whether the unit will perform on your site:
The HCN BM05 Bucket is engineered for Wheel Loaders within HCN's rated weight and hydraulic output range. Send your exact carrier make, model, and pin-to-pin dimensions for a free compatibility confirmation before order placement. OEM-fit brackets are available for Caterpillar, Komatsu, Hitachi, Volvo, Doosan, Bobcat, and 30+ brands.
A quick coupler (also called a quick-attach plate, universal mount, or skid steer interface) is the mechanical connection between a skid steer loader's lift arms and a work attachment. It allows operators to switch between attachments — buckets, forks, augers, snow blowers, and more — in under 60 seconds from inside the cab, versus 10–15 minutes with traditional pin-on connections. HCN quick couplers follow ISO 24410 universal standards and are compatible with all major skid steer brands.
A manual quick coupler requires the operator to exit the machine cab and engage or disengage a physical locking pin. A hydraulic quick coupler (power coupler) locks and unlocks via a cab-mounted switch — the operator never leaves the seat, making tool changes safer and faster. Hydraulic quick couplers are preferred for rental fleets and high-frequency tool-change applications.
HCN hydraulic auger bits are available in diameters from 100 mm to 1,200 mm and standard lengths from 600 mm to 3,000 mm. Flighting options include standard pitch (general soil), rock-flighting (hard ground and caliche), and open-flight (sandy and clay soils). All bits mount on HCN auger drives and most major brand drive units using standard hex or round drive connections.
21,000 m² manufacturing campus in Xuzhou ETDZ — CNC laser cutting, robotic welding, in-house heat treatment, and PLM-controlled production. 400+ models, 500+ patents, export to 60+ countries.
Tour our factory →ISO 9001:2015, ISO 14001, ISO 45001, CE conformity on export lines, and National High-Tech Enterprise status. Full documentation available for tender and OEM audit submissions.
View certifications →Documented deployments: highway compaction in Southeast Asia, airport snow management in Northern Europe, and open-pit rock breaking in Australia — with measurable results.
Read case studies →Not sure which attachment fits your machine? Read our selection guide · Procurement FAQ
Include your machine model, working conditions, and destination country — our sales engineers respond within 24 business hours with pricing, lead time, and bracket fit confirmation.
